I-690V IKhabhinethi-Type Static Var Generator

I-generator ye-690V ye-gerator ye-690V ye-get-var, ekhiqizwa ngokuziqhenya eChina, iyikhambi elibalulekile lamabhizinisi afuna ukulungiswa kwamandla kagesi okuthembekile kanye nokuqina kwamandla kagesi. Yakhelwe izinhlelo zokusebenza ezifunwa kakhulu zezimboni, le generator ye-static var iqinisekisa ukusatshalaliswa kwamandla okungaguquki kanye nokusebenza kahle kohlelo. Uma ufuna ukwenza kabusha ukusetshenziswa kwakho kwamandla, cela isilinganiso namuhla! Ithimba lethu lesazi selilungele ukunikela ngezixazululo ezenziwe ngezifiso ezihambelana nezidingo zakho ezithile.

Thumela Uphenyo

Incazelo Yomkhiqizo

I-690V hlobo lwe-gerator ye-stric ye-690V inikeza isinxephezelo samandla asebenzayo ashukumisayo we-High-Voltage 690V Isigaba sesigaba ezintathu. Kusetshenziswa ukulawula okuthuthukile kweDSP + CPLD kanye ne-topology enezinga ezintathu, kunikeza isinxephezelo esinembile nesisheshayo nesikhathi sokuphendula esingaphansi kwe-10MS. Ukwakhiwa kwekhabethe okuqinile kuqinisekisa ukusebenza okuthembekile ekufuneni izilungiselelo zezimboni futhi kusiza ukulungiswa okulula. Ngomthamo olinganiselwe we-120kvar ku-690V, iphatha kahle izimfuno zamandla asebenzayo ezisetshenziselwa ama-voltage aphezulu.

Incazelo Model:

Uhlobo lwemoto	Into exabanakayo	0.69	50k	/	4L	C
Ikhodi yebhizinisi	I-Static Var Generator	Ileveli ye-Voltage 0.69: 690v ± 20%	Umthamo olinganiselwe (kvar) 100/120 Quarter		I-3L: Isigaba esithathu-sigaba ezintathu I-4L: Isigaba Esithathu-Izintambo ezine	C: i-shisint

Izici:

● Sebenzisa i-DSP + CPLD Yonke i-Digital Control Core, ubuchwepheshe be-topology ezintathu, isu eliphakeme lokuthola amandla i-algorithm ne-PWM yokulawula i-PWM ukufezekisa isinxephezelo esinamandla nesinembile samandla asebenzayo.
● Yamukela ukwakheka okulungiselelwe, okusiza ukuxhumana okuhambisanayo kwamamojula amaningi, kuthatha isikhala esincane futhi kulula ukukugcina.
● Idizayini yokwakheka kwe-Independent Air Ducts kanye nama-WETE WAREHOSEes aqinisekisa ukusebenza okuzinzile kwemishini.
● Yenza isinxephezelo esiguquguqukayo esigcwele samandla asebenzayo asebenzayo namandla okusebenza kabusha we-capacive, futhi axazulule inkinga engalingani emithathu ngasikhathi sinye.
● Ijubane lokuphendula elinamandla kulo mthwalo lisezingeni lama-millisecond, elingafinyelela isinxephezelo esinamandla nesinembile samandla asebenzayo wemithwalo yomthelela.

Izicelo:

Ama-generator we-690V ahlanganisiwe weKhabhinethi alungele izinhlelo zokusebenza zezimboni eziphakeme ezidinga ukulawulwa kwamandla okusebenzayo:

● Ukulungiswa kwamandla aphezulu we-Power Factor:Ukwenza ngcono amandla isici ezinhlelweni ezingama-690V zokusabalalisa, ukunciphisa izindleko zikagesi kanye nokwenza ngcono ukusebenza kahle kohlelo.
● 690v Ukulawulwa Kwemoto Nokusebenza:Ukwenza kahle ukusebenza kanye nokusebenza kahle kwama-690v motors ngokunikeza isinxephezelo samandla asebenzayo ashukumisayo.
● Izinqubo ezisindayo zezimboni ku-690V:Ukuqina kwamandla kagesi nokulawula ukuguquguquka kwamandla okusebenza kabusha ezinqumweni ezisindayo zezimboni ezisebenza ngo-690V.
● Izicelo ze-Mining and Amafutha negesi:Ukuhlinzeka ngokulawulwa kwamandla okusebenzayo okuvuselelayo ezindaweni ezifunwayo njengokumayini kanye nokusebenza kwamafutha kanye negesi kusetshenziswa izinhlelo ezingama-690V.
● Ukuhlanganiswa kwamandla okuvuselelekayo ku-690V:Ukusekela ukuhlanganiswa kwemithombo yamandla evuselelekayo kuma-grid angama-690V angama-690v.

Ama-generator we-690v ahlukaniswa nge-stric we-trabhic anikeza isixazululo esinamandla nesisebenzayo sokwenza kahle ikhwalithi yamandla nokusebenza kwezicelo zamandla aphezulu ezimbonini.

690V Cabinet-type Static Var Generator

Amapharamitha Ezobuchwepheshe:

	I-220V Series	I-380V Series		I-500V Series		I-690V Series
Ukuphakama phezu kolwandle	<2000m, ngenhla kuka-2000m, okukhiqizayo ngokusho kwe-GB / T3859.2
Izinga lokushisa elikhona	-20 ~ + 50 ℃
Umswakama ohlobene	≤90%, Akukho ukubuyiselwa emuva ebusweni lapho izinga lokushisa eliphansi lanyanga zonke lingu-25 ℃
Izinga lokungcola	I-Level III ngezansi
Voltage osebenzayo	I-AC220V ± 20%	AC380V ± 20%		AC500V ± 20%		I-AC690V ± 20%
Imvamisa yokusebenza	I-50hz ± 5%
Kulinganiselwe Isinxephezelo Senkokhelo	I-5kvar	15 / 35/15 / 75 / 100kvar		I-90kvar		I-120kvar
Isakhiwo segridi	L / n	I-3P3w / 3P4W
Inani lamayunithi axhumeke ngokufana	-Nethemba
Ukusebenza kahle komshini okuphelele	≥97%
Imvamisa ekwi-off	32Khz	I-16KHZ		12.8khz		12.8khz
Ukukhetha umsebenzi	Amandla asebenzayo	I-Reactive PO Wer, Reactive PO Wer + Mibalance
Izinga Lokulungiswa Kwamandla Amandla	≥99%	> 95%
Isikhathi sokuphendula esigcwele	<10ms
Isixokoxoko	≤60db	≤60db		≤65DB		≤65DB
Indlela yokulawula	2-Way Rs485 isikhombimsebenzisi (isekela i-GPRS / WIFI)
Ukuvikela	Ukulayisha ngokweqile, isoftware / ye-Hardware ephezulu kakhulu, i-grid screvoltage kanye nokuvinjwa kwamandla, ukwehluleka kwamandla, ukuvikelwa okuphezulu, ukuvikela imvamisa, njll.		Ukulayisha ngokweqile, isoftware / i-Overculvent Overcursent, i-Grid Overvoltage kanye ne-Undervoltage, I-Grid Voltage Imbalince, Amandla Amandla, Ukuhlukumezeka Kwamandla, Ukuvama imvamisa, Ukuvikelwa Kwesilinganiso, njll.
Indlela yokufaka	Rack / kufakwe odongeni				Isikali
Umugqa ongenayo	Emuva okungenayo (uhlobo lwe-rack), okungenayo okungenayo (okufakwe odongeni)				Emuva umugqa ongenayo
Ileveli yokuvikela	I-IP20

Model & Procation:

690V Cabinet-type Static Var Generator

Imodeli yedivayisi yeKhabhinethi
Inombolo yemodeli	Umthamo wesinxephezelo (kvar)	I-System Voltage (V)	Ubukhulu (D * w * h)	Indlela yokupholisa
Gy svg-0.4-200k / 4L-C	200	380 ± 20%	I-800 * 1000 * 2200mm	Ukuphoqelelwa komoya komoya
Gy svg-0.4-250k / 4L-C	250	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.4-300k / 4L-C	300	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.4-400k / 4L-C	400	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.5-270k / 4L-C	270	500 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.69-360k / 4L-C	360	I-690 ± 20%	I-800 * 1000 * 2200mm
