220V I-Static-Type Static Var Generator
I-generator ye-220V yohlobo lwe-static service, ekhiqizwa eChina, yisisombululo esifanele samabhizinisi afuna ukulungiswa kwamandla kagesi okuthembekile kanye nemithetho yeVoltage. Yakhelwe ukusebenza kahle nokuqina, le generator ye-tulic var iqinisekisa ukusebenza kahle kwezicelo zezimboni ezahlukahlukene. Noma ngabe ufuna ukuthuthukisa ukusebenza kahle kwamandla noma ukuthuthukisa ukuthembeka kohlelo, cela isilinganiso namuhla! Iqembu lethu lesazi sezelelesi selilungele ukuhlinzeka ngezixazululo ezihambelana nezezimali zokuhlangabezana nezidingo zakho ezithile.
I-220V Training-Type Static Var Generator (SVG) inikezela ngesinxephezelo samandla asebenzayo ashukumisayo wezinkomo ezingama-220v esisodwa-esigabeni esisodwa nezinhlelo zezigaba ezintathu. Isebenzisa ukulawula kwe-DSP + CPLD yedijithali kanye ne-topology enezinga ezintathu zokunxeshezelwa okusheshayo nokunembile, kuphendula izinguquko zokulayisha ngaphansi kwabangu-10ms. Isikhala esibi sekhabethe esiqinile siqinisekisa ukusebenza okusebenzayo nokulungiswa okulula. Amakhono aqala kusuka ku-5kvar kuya ku-55kvar, ahlalisa imithwalo ehlukahlukene yezimboni nokukhanya kwezimboni ngo-220v.
Incazelo Model:
| Uhlobo lwemoto | Into exabanakayo | 0.22 | I-55k | / | 4L | C |
| Ikhodi yebhizinisi | I-Static Var Generator | Ileveli ye-Voltage I-0.22: 220V |
I-Rated Peract (Kvar) 5/8/7/7/7/7/55kvar | 2l: Isigaba esisodwa I-3L: Isigaba esithathu-sigaba ezintathu I-4L: Isigaba Esithathu-Izintambo ezine |
C: i-shisint |
Izici:
● Sebenzisa i-DSP + CPLD Yonke i-Digital Control Core, ubuchwepheshe be-topology ezintathu, isu eliphakeme lokuthola amandla i-algorithm ne-PWM yokulawula i-PWM ukufezekisa isinxephezelo esinamandla nesinembile samandla asebenzayo.
● Yamukela ukwakheka okulungiselelwe, okusiza ukuxhumana okuhambisanayo kwamamojula amaningi, kuthatha isikhala esincane futhi kulula ukukugcina.
● Idizayini yokwakheka kwe-Independent Air Ducts kanye nama-WETE WAREHOSEes aqinisekisa ukusebenza okuzinzile kwemishini.
● Yenza isinxephezelo esiguquguqukayo esigcwele samandla asebenzayo asebenzayo namandla okusebenza kabusha we-capacive, futhi axazulule inkinga engalingani emithathu ngasikhathi sinye.
● Ijubane lokuphendula elinamandla kulo mthwalo lisezingeni lama-millisecond, elingafinyelela isinxephezelo esinamandla nesinembile samandla asebenzayo wemithwalo yomthelela.
Izicelo:
I-220V Tratic-Type Static Vargerators ilungele izinhlelo zokusebenza ezidinga ukulawulwa kwamandla okusebenzayo ezingeni lama-220V:
● Ukulungiswa Komsebenzi Wamandla Wokuhlala:Ukwenza ngcono amandla Factor emakhaya nasezindlini, kunciphisa izikweletu zikagesi kanye nokwenza ngcono ukusebenza kwezinto ezingama-220V.
● Ukuphathwa kwamandla amabhizinisi amancane:Ukuthuthukisa ikhwalithi yamandla nokunciphisa izindleko zamandla amabhizinisi amancane asebenza kumandla angama-220V.
● Isinxephezelo Sesimboni Esisebenzayo Sezimboni:Ukunikeza isinxephezelo esinamandla kwemithwalo ebabazekayo kuzilungiselelo zezimboni ezikhanyayo zisebenzisa amandla angama-2200.
● 220V Ukulawulwa Kwemoto:Ukuthuthukisa ukusebenza kanye nokusebenza kwama-motors angama-2200 ngokunikeza isinxephezelo samandla asemthethweni okusebenzayo.
● I-I-Photovoltaic System Support (220V):Ukuqina kwamandla kagesi nokwenza ngcono ukusebenza kwezinhlelo ze-Photovoltaic ezingama-220V eziboshwe nge-220V.
I-220V Trainic Tratic Generator i-Varger Generator inikezela ngesisombululo esisebenzayo nesingabizi sokuphatha ikhwalithi yamandla kuzinhlelo zokusebenza ezahlukahlukene ze-220V.
Amapharamitha Ezobuchwepheshe:
| I-220V Series | I-380V Series | I-500V Series | I-690V Series | |||
| Ukuphakama phezu kolwandle | <2000m, ngenhla kuka-2000m, okukhiqizayo ngokusho kwe-GB / T3859.2 | |||||
| Izinga lokushisa elikhona | -20 ~ + 50 ℃ | |||||
| Umswakama ohlobene | ≤90%, Akukho ukubuyiselwa emuva ebusweni lapho izinga lokushisa eliphansi lanyanga zonke lingu-25 ℃ | |||||
| Izinga lokungcola | I-Level III ngezansi | |||||
| Voltage osebenzayo | I-AC220V ± 20% | AC380V ± 20% | AC500V ± 20% | I-AC690V ± 20% | ||
| Imvamisa yokusebenza | I-50hz ± 5% | |||||
| Kulinganiselwe Isinxephezelo Senkokhelo | I-5kvar | 15 / 35/15 / 75 / 100kvar | I-90kvar | I-120kvar | ||
| Isakhiwo segridi | L / n | I-3P3w / 3P4W | ||||
| Inani lamayunithi axhumeke ngokufana | -Nethemba | |||||
| Ukusebenza kahle komshini okuphelele | ≥97% | |||||
| Imvamisa ekwi-off | 32Khz | I-16KHZ | 12.8khz | 12.8khz | ||
| Ukukhetha umsebenzi | Amandla asebenzayo | I-Reactive PO Wer, Reactive PO Wer + Mibalance | ||||
| Izinga Lokulungiswa Kwamandla Amandla | ≥99% | > 95% | ||||
| Isikhathi sokuphendula esigcwele | <10ms | |||||
| Isixokoxoko | ≤60db | ≤60db | ≤65DB | ≤65DB | ||
| Indlela yokulawula | 2-Way Rs485 isikhombimsebenzisi (isekela i-GPRS / WIFI) | |||||
| Ukuvikela | Ukulayisha ngokweqile, isoftware / ye-Hardware ephezulu kakhulu, i-grid screvoltage kanye nokuvinjwa kwamandla, ukwehluleka kwamandla, ukuvikelwa okuphezulu, ukuvikela imvamisa, njll. | Ukulayisha ngokweqile, isoftware / i-Overculvent Overcursent, i-Grid Overvoltage kanye ne-Undervoltage, I-Grid Voltage Imbalince, Amandla Amandla, Ukuhlukumezeka Kwamandla, Ukuvama imvamisa, Ukuvikelwa Kwesilinganiso, njll. | ||||
| Indlela yokufaka | Rack / kufakwe odongeni | Isikali | ||||
| Umugqa ongenayo | Emuva okungenayo (uhlobo lwe-rack), okungenayo okungenayo (okufakwe odongeni) | Emuva umugqa ongenayo | ||||
| Ileveli yokuvikela | I-IP20 | |||||
Model & Procation:
| Imodeli yedivayisi yeKhabhinethi | ||||
|---|---|---|---|---|
| Inombolo yemodeli | Umthamo wesinxephezelo (kvar) | I-System Voltage (V) | Ubukhulu (D * w * h) | Indlela yokupholisa |
| Gy svg-0.4-200k / 4L-C | 200 | 380 ± 20% | I-800 * 1000 * 2200mm | Ukuphoqelelwa komoya komoya |
| Gy svg-0.4-250k / 4L-C | 250 | 380 ± 20% | I-800 * 1000 * 2200mm | |
| Gy svg-0.4-300k / 4L-C | 300 | 380 ± 20% | I-800 * 1000 * 2200mm | |
| Gy svg-0.4-400k / 4L-C | 400 | 380 ± 20% | I-800 * 1000 * 2200mm | |
| Gy svg-0.5-270k / 4L-C | 270 | 500 ± 20% | I-800 * 1000 * 2200mm | |
| Gy svg-0.69-360k / 4L-C | 360 | I-690 ± 20% | I-800 * 1000 * 2200mm | |
