I-500V ye-generator ye-static ye-strative

I-generator ye-500V yohlobo lwe-get-vargerati, eyenziwe eChina, yisixazululo esifanelekile sokwenza ngcono amandla kagesi nokuzinza kwamandla athile ekusebenzeni kwakho. Yakhelwe izindawo ezisebenza kahle, le generator ye-static var iqinisekisa ukusatshalaliswa kwamandla okuthembekile futhi yandisa ukusebenza kahle kwamandla. Uma ufuna ukuthuthukisa ukuqina kohlelo lwakho, cela isilinganiso sanamuhla! Iqembu lethu lilungele ukuhlinzeka ngezixazululo ezihambelana nezezimali ezihlangabezana nezidingo zakho ezihlukile.

Thumela Uphenyo

Incazelo Yomkhiqizo

I-500V TABLETS-TYPE TITAL VER Generator (SVG) inikezela ngesinxephezelo samandla asebenzayo ashukumisayo ngezinhlelo ezingama-500V ezintathu. Isebenzisa i-DSP + CPLD Digital Control Core Colour, Topology Yezinga Ezintathu, kanye nama-algorithms athuthukile wokunxephezelwa okunembile nokuphendula, ukusabela ukulayisha izinguquko ngaphansi kwe-10MS. Ukubiyelwa kweKhabhinethi kuqinisekisa ukusebenza okuthembekile ekufuneni izindawo zezimboni futhi kunikeza ukufinyelela okulula kokulungiswa. Ngomthamo olinganiselwe we-90kvar ngo-500V, ibheka ngempumelelo izimfuno zamandla ezisebenzayo ze-menty-voltage izimboni.

Incazelo Model:

Uhlobo lwemoto	Into exabanakayo	0.5	90K	/	4L	C
Ikhodi yebhizinisi	I-Static Var Generator	Ileveli ye-Voltage I-0.5: 500V ± 20%	Umthamo olinganiselwe (kvar) ikota engama-90		I-3L: Isigaba esithathu-sigaba ezintathu I-4L: Isigaba Esithathu-Izintambo ezine	C: i-shisint

Izici:

● Sebenzisa i-DSP + CPLD Yonke i-Digital Control Core, ubuchwepheshe be-topology ezintathu, isu eliphakeme lokuthola amandla i-algorithm ne-PWM yokulawula i-PWM ukufezekisa isinxephezelo esinamandla nesinembile samandla asebenzayo.
● Yamukela ukwakheka okulungiselelwe, okusiza ukuxhumana okuhambisanayo kwamamojula amaningi, kuthatha isikhala esincane futhi kulula ukukugcina.
● Idizayini yokwakheka kwe-Independent Air Ducts kanye nama-WETE WAREHOSEes aqinisekisa ukusebenza okuzinzile kwemishini.
● Yenza isinxephezelo esiguquguqukayo esigcwele samandla asebenzayo asebenzayo namandla okusebenza kabusha we-capacive, futhi axazulule inkinga engalingani emithathu ngasikhathi sinye.
● Ijubane lokuphendula elinamandla kulo mthwalo lisezingeni lama-millisecond, elingafinyelela isinxephezelo esinamandla nesinembile samandla asebenzayo wemithwalo yomthelela.

Izicelo:

Ama-generator we-500V ahlanganisiwe weKhabhinethi afaneleka kahle kwizicelo ezidinga ukulawulwa kwamandla okusebenzayo okuvuselelwa amandla ezingeni lamandla kagesi aphakathi kwe-500V:

● Ukulungiswa kwamandla okusebenza kwamandla aphakathi nendawo:Ukwenza ngcono amandla isici ezinhlelweni ezingama-500V zokusabalalisa, ukunciphisa izindleko zamandla nokwenza ngcono ukusebenza kahle kohlelo.
● I-500V motor control nokusebenza:Ukuthuthukisa ukusebenza kanye nokusebenza kwezimoto ezingama-500V ngokunikeza isinxephezelo samandla ashukumisayo futhi anembile.
● Ukuhlanganiswa kwamandla okuvuselelekayo ngo-500V:Ukusekela ukuhlanganiswa okuzinzile kwemithombo yamandla evuselelekayo, njengamandla elanga nangomoya, ku-500V grids.
● I-500V yenqubo yenqubo yezezimboni:Ukwenza ngcono ukuqina kanye nokusebenza kahle kwezinqubo ze-500V zezimboni ngokulawula ukuguquguquka kwamandla okusebenza kabusha.
● I-Voltage Stingilization kumanethiwekhi angama-500V:Ukugcina ukuqina kwamandla kagesi kumanethiwekhi okusabalalisa ama-500V, ikakhulukazi phambi kwemithwalo eguquguqukayo.

Ama-generator we-500V ahlanganisiwe weKhabhinethi anikeza isixazululo esithembekile nesisebenzayo sokuphatha ikhwalithi yamandla nokwenza kahle ukusebenza kwamandla aphakathi namandla okusebenza kwamandla okusebenza kwezimboni.

500V Cabinet-type Static Var Generator

Amapharamitha Ezobuchwepheshe:

	I-220V Series	I-380V Series		I-500V Series		I-690V Series
Ukuphakama phezu kolwandle	<2000m, ngenhla kuka-2000m, okukhiqizayo ngokusho kwe-GB / T3859.2
Izinga lokushisa elikhona	-20 ~ + 50 ℃
Umswakama ohlobene	≤90%, Akukho ukubuyiselwa emuva ebusweni lapho izinga lokushisa eliphansi lanyanga zonke lingu-25 ℃
Izinga lokungcola	I-Level III ngezansi
Voltage osebenzayo	I-AC220V ± 20%	AC380V ± 20%		AC500V ± 20%		I-AC690V ± 20%
Imvamisa yokusebenza	I-50hz ± 5%
Kulinganiselwe Isinxephezelo Senkokhelo	I-5kvar	15 / 35/15 / 75 / 100kvar		I-90kvar		I-120kvar
Isakhiwo segridi	L / n	I-3P3w / 3P4W
Inani lamayunithi axhumeke ngokufana	-Nethemba
Ukusebenza kahle komshini okuphelele	≥97%
Imvamisa ekwi-off	32Khz	I-16KHZ		12.8khz		12.8khz
Ukukhetha umsebenzi	Amandla asebenzayo	I-Reactive PO Wer, Reactive PO Wer + Mibalance
Izinga Lokulungiswa Kwamandla Amandla	≥99%	> 95%
Isikhathi sokuphendula esigcwele	<10ms
Isixokoxoko	≤60db	≤60db		≤65DB		≤65DB
Indlela yokulawula	2-Way Rs485 isikhombimsebenzisi (isekela i-GPRS / WIFI)
Ukuvikela	Ukulayisha ngokweqile, isoftware / ye-Hardware ephezulu kakhulu, i-grid screvoltage kanye nokuvinjwa kwamandla, ukwehluleka kwamandla, ukuvikelwa okuphezulu, ukuvikela imvamisa, njll.		Ukulayisha ngokweqile, isoftware / i-Overculvent Overcursent, i-Grid Overvoltage kanye ne-Undervoltage, I-Grid Voltage Imbalince, Amandla Amandla, Ukuhlukumezeka Kwamandla, Ukuvama imvamisa, Ukuvikelwa Kwesilinganiso, njll.
Indlela yokufaka	Rack / kufakwe odongeni				Isikali
Umugqa ongenayo	Emuva okungenayo (uhlobo lwe-rack), okungenayo okungenayo (okufakwe odongeni)				Emuva umugqa ongenayo
Ileveli yokuvikela	I-IP20

Model & Procation:

500V Cabinet-type Static Var Generator

Imodeli yedivayisi yeKhabhinethi
Inombolo yemodeli	Umthamo wesinxephezelo (kvar)	I-System Voltage (V)	Ubukhulu (D * w * h)	Indlela yokupholisa
Gy svg-0.4-200k / 4L-C	200	380 ± 20%	I-800 * 1000 * 2200mm	Ukuphoqelelwa komoya komoya
Gy svg-0.4-250k / 4L-C	250	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.4-300k / 4L-C	300	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.4-400k / 4L-C	400	380 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.5-270k / 4L-C	270	500 ± 20%	I-800 * 1000 * 2200mm
Gy svg-0.69-360k / 4L-C	360	I-690 ± 20%	I-800 * 1000 * 2200mm
