I-220V eyakhiwe ngodonga olusebenzayo

I-220V ekhule ngodonga olusebenzayo, intengo yefektri yokuncintisana, kanye nokusebenza kwekhwalithi ephezulu. Thuthukisa uhlelo lwakho nalesi sixazululo esihlakaniphile, esisebenza kahle. Xhumana nathi namhlanje ngentengo engcono kakhulu yefektri nemiphumela eyenziwe kahle!

Thumela Uphenyo

Incazelo Yomkhiqizo

Isihlungi se-Harmonic esisebenzayo esingu-220v Kusetshenziswa ukulawula okuthuthukile kwe-DSP + CPLD kanye ne-topology enezinga ezintathu, le yunithi ye-compact ihambisa isinxephezelo samanje se-harmonic. Izici ezibalulekile zifaka ibanga lokuhlunga elibanzi le-harmonic (2nd kuya kwe-50th harmonic), isilinganiso esiphakeme sokuhlunga (kuze kufike ku-95%), kanye ne-design modular yokufakwa okulula nokulungisa. Idizayini efakwe odongeni isongela isikhala esibalulekile phansi. Kutholakala ngezilinganiso ezahlukahlukene zamanje (25A kuya ku-150a), i-ahf ezingama-220V efakwe odongeni iqinisekisa ukusebenza okuqinile nokusebenzayo ezindaweni ezibucayi

Incazelo Model:

Uhlobo lwemoto	Ahf	0.4	50A	/	4L	W
Ikhodi yebhizinisi	Isihlungi esisebenzayo se-harmonic	Ileveli ye-Voltage I-0.22: 220V	Umthamo olinganiselwe (kvar) 25/50/75 / 100 / 150a		2L: I-3L eyodwa-Phase-3L: Isigaba Esithathu-Izintambo ezintathu I-4L: Isigaba Esithathu-Izintambo ezine	W: Kufakwe odongeni

Izici:

● Sebenzisa i-DSP + CPLD Yonke i-Digital Control Core, ubuchwepheshe be-topology ezintathu, isu lokutholwa kwe-allorithm ne-PWM lokulawula i-PWM ukufezekisa isinxephezelo esinembile samanje se-harmonic yamanje.
● Yamukela ukwakheka okulungiselelwe, okusiza ukuxhumana okufanayo kwamamojula amaningi, kuthatha isikhala esincane futhi kulula ukuwugcina.
● Idizayini yokwakheka kwe-Independent Air Ducts kanye nama-WETE WAREHOSEes aqinisekisa ukusebenza okuzinzile kwemishini.
● Ingahlunga i-harmonics kunhlobonhlobo ye-harmonics, kusuka ku-2 kuye ku-50 Harmonics, futhi ixazulule inkinga yokungalingani kwesigaba ezintathu ngasikhathi sinye.
● Izinga lokuhlunga le-harmonic liphezulu. Uma umthamo uvumela, isilinganiso sokuhlunga samanje se-harmonic singaba phezulu njengo-95%. Setha okungu-100% okukhawulelwe kokukhawulelwa kwamanje ukuqinisekisa ukusebenza kwesikhathi eside kwemishini.

Izicelo:

Izihlungi ezi-220v ezikhule ngodonga zibalulekile ukuze zilondoloze ikhwalithi yamandla kuzilungiselelo ezahlukahlukene:

● Amabhizinisi amancane aphakathi nendawo:Ukuvikela imishini ebucayi kanye nokuqinisekisa ukusebenza okuthembekile kwamakhompyutha, ama-elekthronikhi, neminye imithwalo ebucayi.
● Izicelo zokuhlala:Ukuthuthukisa ikhwalithi yamandla emizini enemishini ekhiqizwayo ephezulu yokulimaza.
● Izikhungo zezokwelapha:Ukunikeza amandla ahlanzekile emishini yezokwelapha ebucayi emitholampilo nasezikhungweni zezempilo ezincane.
● Izindawo Zokuthengisa:Ukuqinisekisa ukusebenza okubushelelezi kwezinhlelo ze-Point-of-Sale kanye namanye amadivayisi we-elekthronikhi.
● Ama-laboratories:Ukuvikela imishini yelebhu ebucayi ebucayi kusuka ekuhlanekezelweni kwe-harmonic.

I-220V esebenzayo e-Wallonic Actimic Harmonic inikeza isixazululo esisebenzayo nesisebenzayo sokwenza kahle ikhwalithi yamandla kuhlelo lokusebenza lwe-220V.

220V Wall-mounted Active Harmonic Filter

Amapharamitha Ezobuchwepheshe:

	I-220V Series	I-380V Series	I-500V Series		I-690V Series
Ukuphakama phezu kolwandle	<2000m, ngenhla kuka-2000m, okukhiqizayo ngokusho kwe-GB / T3859.2
Izinga lokushisa elikhona	-20 ~ + 50 ℃
Umswakama ohlobene	≤90%, Akukho ukubuyiselwa emuva ebusweni lapho izinga lokushisa eliphansi lanyanga zonke lingu-25 ℃
Izinga lokungcola	I-Level III ngezansi
Voltage osebenzayo	I-AC220V ± 20%	AC380V ± 20%	AC500V ± 20%		I-AC690V ± 20%
Imvamisa yokusebenza	I-50hz ± 5%
Isinxephezelo samanje	25A	25/50/75/100 / 150a	100A		100A
Isakhiwo segridi	L / n	I-3P3w / 3P4W	I-3P3w / 3P4W		I-3P3w / 3P4W
Inani lamayunithi axhumeke ngokufana	-Nethemba
Ukusebenza kahle komshini okuphelele	≥97%
Isakhiwo segridi	32Khz	I-16KHZ	12.8khz		12.8khz
Uhla lwenxephezelo	2 ~ 50times, isilinganiso esisodwa sokunxeshezelwa siyakwazi ukuguquguquka
Ukukhetha umsebenzi	Amandla asebenzayo	Amandla asebenzayo, amandla asebenzayo + asymmetry
Izinga Lokulungiswa Kwamandla Amandla	≥95%	> 92%
Amandla okuhlunga angathathi hlangothi		Amandla wokuhlunga angathathi hlangothi ahlabelelayo izikhathi ezi-3 zendlela yokuhlunga kwesigaba
Isikhathi sokuphendula esigcwele	<10ms	<40ms		<40ms	<40ms
Isixokoxoko	≤60db	≤60db		≤65DB	≤65DB
Indlela yokulawula	2-Way Rs485 isikhombimsebenzisi (isekela i-GPRS / WIFI)
Ukuvikela	Ukulayisha ngokweqile, isoftware / ye-Hardware ephezulu kakhulu, i-grid screvoltage kanye nokuvinjwa kwamandla, ukwehluleka kwamandla, ukuvikelwa okuphezulu, ukuvikela imvamisa, njll.	Ukulayisha ngokweqile, isoftware / ye-Hardware Overcursent, i-Grid Overvoltage kanye ne-Undervoltage, I-Grid Voltage Mibance, Amandla Amandla, Ukuhlupheka Okuphezulu, Ukuvikelwa Kwemvamisa, Ukuvikelwa Kwemvamisa, Ukuvikelwa Okufushane, njll.
Indlela yokufaka	Rack / kufakwe odongeni		Isikali
Umugqa ongenayo	Emuva okungenayo (uhlobo lwe-rack), okungenayo okungenayo (okufakwe odongeni)		Emuva umugqa ongenayo
Ileveli yokuvikela	I-IP20

Model & Procation:

220V Wall-mounted Active Harmonic Filter

Amamodeli
Inombolo yemodeli	Kukalwe manje (a)	I-System Voltage (V)	Ubukhulu (D * w * h)	Indlela yokupholisa
Gy apf-0.22-25a / 2L-R / W	25	220	220 * 330 * 160mm	Ukuphoqelelwa komoya komoya
Gy apf-0.4-25a / 4L-R / W	25	380 ± 20%	460 * 490 * 89mm
Gy apf-0.4-50A / 4L-R / W	50	380 ± 20%	460 * 490 * 89mm
Gy apf-0.4-75a / 4L-R / W	75	380 ± 20%	500 * 510 * 190mm
Gy apf-0.4-100a / 4L-R / w	100	380 ± 20%	500 * 550 * 240mm
Gy apf-0.4-150a / 4L-R / W	150	380 ± 20%	500 * 550 * 240mm
Gy apf-0.5-100a / 4L-R / w	100	500 ± 20%	495 * 675 * 275mm
Gy apf-0.69-100a / 4L-R / w	100	I-690 ± 20%	495 * 675 * 275mm
