I-690V efakwe e-static generator

Ufuna i-generator ethembekile engu-690V UGeya unikeza izixazululo eziphakeme ezisebenza kahle ngobuchwepheshe obuthuthukisiwe ngekhwalithi yamandla azinzile. Yakhelwe ukuqina kanye nokusebenza kahle, le mishini inciphisa izindleko futhi ithuthukise ukusebenza kahle. Cela isilinganiso sakho manje futhi uthole ukuthi imikhiqizo yethu ingathuthukisa kanjani ibhizinisi lakho!

Thumela Uphenyo

Incazelo Yomkhiqizo

Ukuchazwa Komkhiqizo:

I-690V ebekwe ngo-690V Ukulawulwa kwe-DSP + CPLD yedijithali kanye ne-topology enezinga ezintathu, le SVG inikeza isinxephezelo esisheshayo nesinembile nesikhathi sokuphendula esingaphansi kwama-10ms. Idizayini esezingeni elifanele inika amandla umthamo ohlanganayo, kanye nokucushwa okufakwe odongeni kunciphisa izidingo zonyawo. Le SvG inxephezela ngempumelelo amandla womabili amangalisayo futhi avume ukusebenza kwamandla, ethuthukisa isici samandla kanye nokwenza ngcono amandla aphezulu. Ngomthamo olinganiselwe we-120kvar, i-SVG ebekwe ngodonga engu-690V inikeza isixazululo esiqinile sezicelo eziphakeme ze-voltage.

Incazelo Model:

Uhlobo lwemoto	Into exabanakayo	0.69	I-100k	/	4L	W
Ikhodi yebhizinisi	I-Static Var Generator	Ileveli ye-Voltage 0.69: 690v ± 20%	Umthamo olinganiselwe (kvar) 100/120 Quarter		I-3L: Isigaba esithathu-sigaba ezintathu I-4L: Isigaba Esithathu-Izintambo ezine	W: Kufakwe odongeni

Izici:

● Sebenzisa i-DSP + CPLD Yonke i-Digital Control Core, ubuchwepheshe be-topology ezintathu, isu eliphakeme lokuthola amandla i-algorithm ne-PWM yokulawula i-PWM ukufezekisa isinxephezelo esinamandla nesinembile samandla asebenzayo.
● Yamukela ukwakheka okulungiselelwe, okusiza ukuxhumana okuhambisanayo kwamamojula amaningi, kuthatha isikhala esincane futhi kulula ukukugcina.
● Idizayini yokwakheka kwe-Independent Air Ducts kanye nama-WETE WAREHOSEes aqinisekisa ukusebenza okuzinzile kwemishini.
● Yenza isinxephezelo esiguquguqukayo esigcwele samandla asebenzayo asebenzayo namandla okusebenza kabusha we-capacive, futhi axazulule inkinga engalingani emithathu ngasikhathi sinye.
● Ijubane lokuphendula elinamandla kulo mthwalo lisezingeni lama-millisecond, elingafinyelela isinxephezelo esinamandla nesinembile samandla asebenzayo wemithwalo yomthelela.

Izicelo:

Ama-generator we-tulic efakwe odongeni ebekwe ngodonga alungele ukufunwa kwezicelo ezifunwayo ezidinga ukulawulwa kwamandla okusebenzayo:

● Ukusebenza Kwezimboni Ezisindayo (690V):Ukugcina ukuzinza kwamandla kagesi kanye nokwenza ngcono amandla esicini ezimbonini ezisindayo ezisebenza ngo-690V.
● Isilawuli semoto ephezulu ye-voltage (690V):Ukunxephezela ukufunwa kwamandla okusebenzayo kusuka kuma-motor aphezulu amavoti kuzinhlelo ezingama-690V, ngcono ukusebenza kahle kwezimoto kanye nokunciphisa ukulahleka kwamandla.
● Amanethiwekhi okusatshalaliswa kwamandla angama-690V:Ukuthuthukisa ikhwalithi yamandla nokuqina ezinhlelweni zokusabalalisa ezingama-690V.
● Imayini kanye ne-OIL negesi (690V):Ukunikeza isinxephezelo samandla athembekile okusebenzayo ezindaweni ezinokhahlo zivame ukusebenzisa izinhlelo ezingama-690V.

Ama-generator afakwe odongeni olwadongeni anikezela ngesixazululo esinamandla nesisebenzayo sokwenza kahle ikhwalithi yamandla nokuqina kuma-gree-voltage kagesi kagesi amathathu.

690V Wall-mounted Static Var Generator

Amapharamitha Ezobuchwepheshe:

	I-220V Series	I-380V Series		I-500V Series		I-690V Series
Ukuphakama phezu kolwandle	<2000m, ngenhla kuka-2000m, okukhiqizayo ngokusho kwe-GB / T3859.2
Izinga lokushisa elikhona	-20 ~ + 50 ℃
Umswakama ohlobene	≤90%, Akukho ukubuyiselwa emuva ebusweni lapho izinga lokushisa eliphansi lanyanga zonke lingu-25 ℃
Izinga lokungcola	I-Level III ngezansi
Voltage osebenzayo	I-AC220V ± 20%	AC380V ± 20%		AC500V ± 20%		I-AC690V ± 20%
Imvamisa yokusebenza	I-50hz ± 5%
Kulinganiselwe Isinxephezelo Senkokhelo	I-5kvar	15 / 35/15 / 75 / 100kvar		I-90kvar		I-120kvar
Isakhiwo segridi	L / n	I-3P3w / 3P4W
Inani lamayunithi axhumeke ngokufana	-Nethemba
Ukusebenza kahle komshini okuphelele	≥97%
Imvamisa ekwi-off	32Khz	I-16KHZ		12.8kHz		12.8kHz
Ukukhetha umsebenzi	Amandla asebenzayo	I-Reactive PO Wer, Reactive PO Wer + Mibalance
Izinga Lokulungiswa Kwamandla Amandla	≥99%	> 95%
Isikhathi sokuphendula esigcwele	<10ms
Isixokoxoko	≤60db	≤60db		≤65DB		≤65DB
Indlela yokulawula	2-Way Rs485 isikhombimsebenzisi (isekela i-GPRS / WIFI)
Ukuvikela	Ukulayisha ngokweqile, isoftware / ye-Hardware ephezulu kakhulu, i-grid screvoltage kanye nokuvinjwa kwamandla, ukwehluleka kwamandla, ukuvikelwa okuphezulu, ukuvikela imvamisa, njll.		Ukulayisha ngokweqile, isoftware / i-Overculvent Overcursent, i-Grid Overvoltage kanye ne-Undervoltage, I-Grid Voltage Imbalince, Amandla Amandla, Ukuhlukumezeka Kwamandla, Ukuvama imvamisa, Ukuvikelwa Kwesilinganiso, njll.
Indlela yokufaka	Rack / kufakwe odongeni				Isikali
Umugqa ongenayo	Emuva okungenayo (uhlobo lwe-rack), okungenayo okungenayo (okufakwe odongeni)				Emuva umugqa ongenayo
Ileveli yokuvikela	I-IP20

Model & Procation:

690V Wall-mounted Static Var Generator

Amamodeli
Inombolo yemodeli	Umthamo wesinxephezelo (kvar)	I-System Voltage (V)	Ubukhulu (D * w * h)	Indlela yokupholisa
Gy svg-0.22-5k / 2L-R / W	5	220	220 * 330 * 160mm	Ukuphoqelelwa komoya komoya
Gy svg-0.4-15k / 4L-R / W	15	380 ± 20%	460 * 490 * 89mm
Gy svg-0.4-35k / 4L-R / W	35	380 ± 20%	460 * 490 * 89mm
Gy svg-0.4-50k / 4L-R / W	50	380 ± 20%	500 * 510 * 190mm
Gy svg-0.4-75k / 4L-R / W	75	380 ± 20%	500 * 550 * 240mm
Gy svg-0.4-100k / 4L-R / W	100	380 ± 20%	500 * 550 * 240mm
Gy svg-0.5-90k / 4L-R / W	90	500 ± 20%	495 * 675 * 275mm
Gy SVG-0.69-120K / 4L-R / W	120	I-690 ± 20%	495 * 675 * 275mm
